Synology Unified Controller UC3200

Productcode: UC3200 | EAN/UPC: 4711174723126

€ 5.924,88 excl.btw

Synology Unified Controller UC3200 - Hard drive array - 12 bays (SAS) - SAS (external) - rack-mountable - 2U

High-performance, active-active storage solution to provide non-disruptive iSCSI services
Resilient cache protection mechanism to prevent data loss
Instant data protection with built-in snapshot and replication technologies

Op voorraad: 0 stuk(s)

Levertijd:

Product:
Synology Unified Controller UC3200

€ 7169,10 incl. 21% btw € 5924,88excl. 21% btw

Winkelwagen Offerte

Stuur mij een notificatie bij voorraad

Omschrijving

Synology Unified Controller UC3200 - Hard drive array - 12 bays (SAS) - SAS (external) - rack-mountable - 2U

Product features

Powerful and flexible scalability
UC3200 is an affordable yet reliable IP SAN solution for mission-critical environments. It delivers outstanding performance and allows you to start small and grow in the future.
Uncompromising reliability
The active-active controller design maximizes the system uptime for your important applications. The inter-connectivity through high-speed NTB between the two controllers allows one of them to seamlessly take over the service when the other breaks down.

Specificaties

General

Device Type

Hard drive array

Enclosure Type

Rack-mountable - 2U

Chassis

Installed Devices / Modules Qty

Supported Devices / Modules Qty

Supported Drives

SAS

Storage

HDD Array External Interface

SAS

Maximum LUNs

128

Processor

CPU

2 x Xeon 2.4 GHz

Storage Controller

Type

RAID

Installed Qty

Interface Type

SAS

Cache / Buffer Size (Max)

8 GB

RAID Level

RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID F1

Storage Controller (2nd)

Installed Qty

Hard Drive

Type

No HDD

Expansion / Connectivity

Expansion Bays

12 (total) / 12 (free) x hot-swap - 2.5" / 3.5" shared

Expansion Slots

2 (total) / 2 (free) x PCIe 3.0 x8

Interfaces

2 x SAS
4 x Ethernet 1000Base-T - RJ-45
2 x Ethernet 10Gb - RJ-45
2 x serial - 9 pin D-Sub (DB-9)

Miscellaneous

Features

Built-in 4 cooling fans, SNMP support

Compliant Standards

RoHS

Included Accessories

Accessory pack

Power

Power Device

2 x internal power supply

Max Supported Qty

Power Redundancy

Yes

Power Redundancy Scheme

1+1

Voltage Required

AC 120/230 V - 50/60 Hz

Dimensions & Weight

Width

43.05 cm

Depth

69.2 cm

Height

8.8 cm

Weight

19.7 kg

Manufacturer Warranty

Service & Support

Limited warranty - 5 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

35 °C

Humidity Range Operating

5 - 95%

This data is supplied by 1WorldSync and matched through an automated process. Truedata is not responsible for errors in this data.
