General
Product Form Factor
Rack-mountable - 2U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Processor / Chipset
CPU Upgradability
Upgradable
Cache Memory
Installed Size
L3 Cache - 64 MB
RAM
Installed Size
32 GB (installed) / 6 TB (max)
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Slots
12 (Total) / 11 (empty)
Features
HPE SmartMemory, registered, slots 13 - 24 are available in two-processor configuration only, single rank
Configuration Features
1 x 32 GB
Hard Drive
Storage Controller
Storage Controller Name
HPE MR408i-o Gen11 SPDM
Optical Storage
Monitor
Graphics Controller
Networking
Interface (Bus) Type
Open Compute Project mezzanine (OCP) 3.0
Ethernet Ports
2 x 10 Gigabit Ethernet
Ethernet Controller
Broadcom BCM57416
Data Link Protocol
Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 6
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 (x16 mode)
Interfaces
1 x HPE iLO (1 in front) (service port)
5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal)
1 x VGA
2 x LAN (10Gigabit Ethernet)
Miscellaneous
Included Accessories
6 x standard fans, HPE Gen11 rail kit without CMA
Compliant Standards
AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 100-120/200-240 V
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
