General
Product Form Factor
Tower - 4U
Processor / Chipset
CPU
Intel Xeon Silver 4208
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Hyper-Threading Technology
CPU Socket
FCLGA3647 Socket
Cache Memory
Installed Size
L3 Cache - 11 MB
RAM
Installed Size
16 GB (installed) / 1.5 TB (max)
Technology
DDR4 SDRAM - Advanced ECC
Effective Memory Speed
2400 MHz
Rated Memory Speed
2933 MHz
Slots
12 (Total) / 11 (empty)
Features
Single rank, registered, HPE SmartMemory, slots 13 - 24 are available in two-processor configuration only
Configuration Features
1 x 16 GB
RAM Supported
3 TB Load-Reduced
1.5 TB registered
Hard Drive
Storage Controller
Type
1 x RAID - PCIe 3.0 x8
Controller Interface Type
SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name
HPE Smart Array P408i-a SR Gen10
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Optical Storage
Monitor
Graphics Controller
Video Interfaces
DisplayPort, VGA
Networking
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HPE 369i
Data Link Protocol
Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0
Remote Management Controller
Integrated Lights-Out 5
Features
PXE support, Wake on LAN (WoL)
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 1 (free) x PCIe 3.0 x8 - full-length, full-height (x4 mode)
2 (total) / 2 (free) x PCIe 3.0 x16 - full-length, full-height
1 (total) / 1 (free) x microSD Card (internal)
Interfaces
1 x VGA
1 x serial
4 x LAN (Gigabit Ethernet)
1 x HPE iLO - RJ-45 (1 rear)
5 x USB 3.0 (2 front, 2 rear, 1 internal)
1 x USB 2.0 (1 internal)
1 x HPE iLO - Type A (1 in front) (service port)
1 x DisplayPort
Miscellaneous
Included Accessories
6 x standard fans
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock eye
Security Slot Type
Kensington security slot
Compliant Standards
ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, Energy-Related Products (ErP) Lot 9
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
(50/60 Hz)
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
