General
Product Form Factor
Rack-mountable - 2U
Built-in Devices
Led panel
Localisation
Region: Worldwide
Processor / Chipset
CPU
Intel Xeon Silver 4210R
CPU Upgradability
Upgradable
Cache Memory
Cache Per Processor
13.75 MB
RAM
Installed Size
32 GB (installed) / 3 TB (max)
Effective Memory Speed
2400 MHz
Rated Memory Speed
2933 MHz
Memory Specification Compliance
PC4-23466
Slots
24 (Total) / 23 (empty)
Configuration Features
1 x 32 GB
RAM Supported
3 TB Load-Reduced - ECC
1.5 TB registered - ECC
192 GB Non-Volatile - ECC
Hard Drive
Storage Controller
Controller Interface Type
SAS 12Gb/s
Storage Controller Name
Broadcom MegaRAID MR416i-a
Optical Storage
Card Reader
Supported Flash Memory Cards
microSD
Monitor
Graphics Controller
Networking
Ethernet Ports
4 x Gigabit Ethernet
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external Universal Media Bay
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x FlexibleLOM
1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height
2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height
1 (total) / 1 (free) x microSD Card (internal)
Interfaces
1 x HPE iLO - Type A (1 in front)
5 x USB 3.0 (1 front, 2 rear, 2 internal)
1 x HPE iLO - RJ-45 (1 rear)
4 x LAN (Gigabit Ethernet) - RJ-45 (4 rear)
1 x VGA (1 rear)
Miscellaneous
Included Accessories
4 standard fans, CPU standard heatsink, HPE Easy Install Rails with CMA
Compliant Standards
AES, FIPS 140-2, WEEE, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, UEFI, ACPI 6.3, SMBIOS 3.2
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 100-240 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
