General
Printer Type
Label printer - direct thermal / thermal transfer - monochrome
Printer
Print Speed
Up to 300 mm/sec - max speed - 300 dpi
Built-in Devices
3.5 inch LCD touch screen
Connectivity Technology
Wired
Interface
USB 2.0, LAN, USB 2.0 host, RS232
Max Resolution (B&W)
300 dpi
Language Simulation
ZPL II, Intermec Printer Language (IPL), Extensible Mark-up Language (XML), DPL, ZSim2
Features
Realtime clock, Black Mark sensor, gap sensor, integrated label verification, dual label stop sensor
Barcodes
UCC/EAN-128, ISBT 128, HIBCC, UPC, Postnet, AIAG, OGMARS, GM1724
Processor
Processor
ARM Cortex-A9 1 GHz
RAM
Technology / Form Factor
DDR3 SDRAM
Flash Memory
Media Handling
Media Type
Labels, continuous labels, non-laminated labels
Max Media Size
Roll (2 - 11.4 cm)
Min Media Size (Custom)
3 mm
Media Sizes
Roll (2 - 11.4 cm)
Max Printing Width
105.7 mm
Media Thickness Range
0.076 mm - 0.25 mm
Roll Maximum Outer Diameter
212.7 mm
Media Feeders
1 x manual - Roll (11.4 cm)
Networking
Expansion / Connectivity
Connections
2 x USB 2.0 host - 4 pin USB Type A ¦ 1 x USB 2.0 - 4 pin USB Type B ¦ 1 x LAN - RJ-45 ¦ 1 x RS-232 - 9 pin D-Sub (DB-9)
Miscellaneous
Features
Foldable clear media door
Compliant Standards
FCC Class A certified, EN55022 Class A
Power
Power Device
Power supply - internal
Voltage Required
AC 100 - 240 V
Frequency Required
45 - 65 Hz
Power Consumption Operational
200 Watt
Power Factor Correction
Yes
Software / System Requirements
Software Included
InterDriver Windows, CUPS driver for Linux, Honeywell Device Types, Honeywell Label Design and Print Package
Environmental Standards
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 85% (non-condensing)
Dimensions & Weight
