General
Host Connectivity
Gigabit Ethernet / 2.5 Gigabit Ethernet
Enclosure Type
Rack-mountable - 1U
Total Storage Capacity
0 GB
Installed Devices / Modules Qty
0 (installed) / 4 (max)
Processor / Memory
Processors Installed
1 x ARM A55 2 GHz
RAM
4 GB (installed) / 4 GB (supported)
Flash Memory Installed
4 GB
Storage Controller
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID 50, RAID 60
Networking
Data Link Protocol
10Mb LAN, 100Mb LAN, 1GbE, 2.5GbE
Network / Transport Protocol
DHCP, iSCSI, DDNS, SMB, PPTP, L2TP, IPSec
Remote Management Protocol
SNMP 2, SNMP 3, SSH, HTTP, HTTPS, Telnet, TFTP
Network Services Compatibility
Apple File Protocol (AFP), Microsoft CIFS, Server Message Block (SMB), DHCP, DDNS, HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), Network File System v3 (NFS v3), Network File System v4 (NFS v4)
Features
VJBOD Cloud, EXT4 file system, online RAID level migration, SSD trim, FTP server, file station, Access Control List (ACL) support, scheduler, system log, port trunking, VLAN support, DHCP server, anti-malware protection, firewall protection, Qsync, Qsirch, QuMagie, VPN support, LDAP support, RADIUS support, Q'center (NAS CMS), QmailAgent, QuWAN, SQL Server, 256-bit encryption, cloud backup, Apple Time Machine compatible, anti-virus protection, wake on LAN (WOL), Jumbo Frames support, built-in buzzer
Encryption Algorithm
SSL, 256-bit AES, TLS 1.0, TLS 1.1, TLS 1.2, TLS 1.3
Security DVR
Expansion / Connectivity
Expansion Bays
4 (total) / 4 (free) x hot-swap - 2.5" / 3.5"
Interfaces
2 x 2.5 Gigabit Ethernet - RJ-45
2 x USB 3.2 Gen 1 - Type A
Miscellaneous
Cables Included
1 x network cable
Features
Built-in 3 cooling fans, hardware encryption, reset button, Secure Erase, dual boot, kensington security slot
Security Slot Type
Kensington security slot
Included Accessories
Power cable, 16 x flat head screws (for 3.5" HDD), 12 x flat head screws (for 2.5" HDD), 2 x hangers, 2 x holders
Power
Power Device
External power adapter
Voltage Required
AC 100-240 V
Power Consumption Operational
23.74 Watt
Power Consumption Stand by
9.32 Watt
Software / System Requirements
Storage Operating System
QNAP QTS 5.2.1
Software Included
IronWolf Health Management
OS Required
Apple MacOS X 10.10 or later, Ubuntu 14.04, CentOS 7.0, Red Hat Enterprise Linux 6.6, SuSE Linux 12 or later, IBM AIX 7, Oracle Solaris 10 or later, Microsoft Windows 7 / 8 / 10 / 11, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2022
Manufacturer Warranty
Service & Support
Limited warranty - 2 years
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
