General
Device Type
Security appliance
Processor / Memory / Storage
Hard Drive
SSD 100 GB x 1 - mSATA
Networking
Form Factor
Rack-mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Performance
Inspection throughput: 1 Gbps
Multiprotocol firewall throughput: 500 Mbps
Connection rate: 10000 connections per second
Application control (AVC) throughput: 450 Mbps
Application control (AVC) and IPS throughput: 250 Mbps
VPN throughput (3DES/AES): 175 Mbps
Application control (AVC) or IPS sizing throughput: 180 Mbps
Capacity
Concurrent sessions: 100000
Cisco AnyConnect Premium/Apex VPN peers: 2 (maximum 50)
IPSec VPN peers: 10 (upgradeable to 50)
Virtual interfaces (VLANs): 5 (upgradeable to 30)
Features
Firewall protection, VPN support, VLAN support
Expansion / Connectivity
Interfaces
1 x 1000Base-T (management) - RJ-45
1 x USB 2.0 - Type A
1 x mini-USB
1 x console - RJ-45
8 x 1000Base-T - RJ-45
Miscellaneous
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 60950, EN 61000-3-2, EN55022, IEC 60950, EN 61000-3-3, EN55024, UL 60950, VCCI V-3, AS/NZS 60950, CAN/CSA C22.2 No. 60950, CNS 13438, EN 301 489-7, EN 301 489.4, EN 301 489-1, EN 301 489-17, EN 300386, EN 301 489-24
Power
Power Device
External power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Manufacturer Warranty
Service & Support
Limited warranty - advance hardware replacement - 90 days - response time: 10 days
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
