General
Device Type
Radio access point
Networking
Connectivity Technology
Wireless
Data Transfer Rate
2.4 Gbps
Line Coding Format
CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Spread Spectrum Method
OFDM, DSSS
Frequency Band
2.4 GHz, 5 GHz
Performance
Maximum data rate (2.4 GHz): 1.150 Mbps
Maximum data rate (5 GHz): 2.4 Gbps
Aggregate bandwidth: 3.55 Gbps
Capacity
Wireless clients per Wi-Fi radio: 1024
OFDMA units: 37
BSSIDs per radio: 16
Status Indicators
System, status
Features
Trusted Platform Module (TPM), LACP support, Adaptive Radio Management (ARM), Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Direct Sequence Spread Spectrum (DSSS), Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), ClientMatch, cyclic shift diversity (CSD), AppRF technology, MU-MIMO technology, packet aggregation A-MPDU, packet aggregation A-MSDU, Air Monitor (AM), Intelligent Power Monitoring (IPM), Dynamic Frequency Selection (DFS), Secure Core Technology (SCT), High-Throughput (HT) support, 4x4 MU-MIMO technology, LED off mode, Energy-Efficient Ethernet (EEE), Orthogonal Frequency Division Multiplexing (OFDM), Aruba AirMatch, spectrum analyser, Very High Throughput (VHT) support, security slot (Kensington security lock compatible), Orthogonal Frequency Division Multiple Access (OFDMA), unified AP support, custom deep-sleep mode, High Efficiency (HE) support, Target Wait Time (TWT)
Encryption Algorithm
WPA, WPA2, WPA3
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.3bz, IEEE 802.3bt, IEEE 802.11ax
Aerial
Directivity
Omni-directional
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Communications Technology
Bluetooth, Zigbee
Expansion / Connectivity
Interfaces
1 x HPE Smart Rate - RJ-45
1 x 5GBase-T - RJ-45
1 x USB 2.0 - Type A
1 x console - micro-USB
Miscellaneous
Included Accessories
Base bracket
Compliant Standards
EN 60950, IEC 60950, UL 60950, UL 2043, FCC, EN 60601-1-2, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, RED 2014/53/EU
Power
Power Over Ethernet (PoE) Supported
PoE
Power Consumption Operational
26.4 Watt
Software / System Requirements
OS Required
ArubaOS, InstantOS
Dimensions & Weight (Shipping)
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
5 - 93% (non-condensing)
