General
Device Type
Switch - 8 ports - smart
Enclosure Type
Desktop, rack-mountable
Ports
8 x 10/100/1000 (PoE+) + 2 x 10/100/1000 (uplink) + 2 x Gigabit SFP (uplink)
Power Over Ethernet (PoE)
PoE+
Performance
Switching capacity: 24 Gbps ¦ Forwarding rate: 17.8 Mpps ¦ Packet buffer size: 525 KB
MAC Address Table Size
8K entries
Routing Protocol
IGMPv2, IGMP, IGMPv3, RSTP, STP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, SSH, CLI, NTP, ICMP, DHCP, RSTP, RADIUS
Encryption Algorithm
SSL, SHA-2
Authentication Method
Secure Shell (SSH), RADIUS
Features
Flow control, IGMP snooping, Syslog support, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, WFQ, DHCP snooping, LLDP support, DHCP relay, LACP, DHCP client, MIB, dual firmware images, SPQ, NDP, port isolation, CoS, 8KV/15KV ESD Protector, DSCP support, IGMP filtering, CPU protection, 4KV Surge protection, Loop Guard, LLDP-MED, EEE, WRR, VLAN trunking
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
Expansion / Connectivity
Interfaces
8 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-T RJ-45 uplink ¦ 2 x 1000Base-X SFP uplink
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
160.3 Watt
Miscellaneous
Rack Mounting Kit
Included
Compliant Standards
FCC, RoHS, BSMI CNS 13438, C-Tick Class A, LVD, BSMI CNS 14336-1, EN 62368-1
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
-20 °C
Max Operating Temperature
50 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 95% (non-condensing)
