General
Device Type
Switch - 6 ports
Enclosure Type
Wall-mountable
Ports
4 x 10/100/1000 (4 PoE+) + 2 x SFP
Performance
Forwarding bandwidth: 6 Gbps
Switching bandwidth: 12 Gbps
Forwarding rate (64-byte packets): 8.928 Mpps
Capacity
VLANs supported: 64
Port channels: 4
VLAN IDs: 4094
Queues: 4
MAC Address Table Size
15000 entries
Remote Management Protocol
SNMP 3, DHCP, RMON
Authentication Method
MACAuth, TACACS+, RADIUS
Features
Fanless, LACP, VTP, LLDP support, LLDP-MED, CoAP support, Private VLAN, secure boot, EEE
Compliant Standards
IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.3az
Status Indicators
Link/activity, PoE, port status, speed
Expansion / Connectivity
Interfaces
4 x 10/100/1000 Base-T (PoE) RJ-45
2 x SFP
Miscellaneous
Compliant Standards
AS/NZS 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1, AS/NZS CISPR22:2004 Class A, CISPR 22, CISPR 24, EN55022, EN55024, FCC CFR47 Part 15 A, ICES-003 issue 6:2016, KN32:2015, KN35:2015, RoHS, TCVN 7189: 2009, TCVN 7317:2003, V-3/2015.04, IEC 62368-1, UL 62368-1
Software / System Requirements
Software Included
LAN Lite Software
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - advance hardware replacement - lifetime - response time: next business day
Technical support - 90 days
Environmental Parameters
Min Operating Temperature
-5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-25 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 95% (non-condensing)
