General
Connectivity Technology
Wired
Data Link Protocol
10 Gigabit Ethernet, 2.5 Gigabit Ethernet
Remote Management Protocol
HTTP, CLI
Features
QoS, WWAN support, ZTP, SD-WAN support, 4x4 MIMO technology, SUDI
Compliant Standards
EN 61000-3-2, IEC 61000-3-2, EN55024, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, FDA, EN 301 489-1, FCC CFR47 Part 15 B Class A, EN 300 386, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, AS/NZS CISPR 32 Class A, EN 62368-1, IEC 62368-1, IEC/EN 61000-4-11, IEC/EN 61000-4-2, EN 55032 Class A, EN 55032, CISPR 32 Class A, EN 301 489-19, CAN/CSA-C22.2 No. 60950-1, VCCI-CISPR 32:2016 Class A, EN 55035, IEC/EN 61000-3-3, IEC/EN 60825, ETSI EN 301 489-52
Communications
Type
Wireless cellular modem
Cellular Band
LTE B13, LTE B17, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B25, LTE B26, LTE B5, LTE B39, LTE B28, LTE B29, LTE B8, LTE B66, LTE B30, LTE B40, LTE B41, LTE B38, LTE B18, LTE B19, LTE B46, LTE B14, LTE B32, LTE B42, LTE B43, LTE B48, LTE B71, 5G n78, 5G n1, 5G n2, 5G n3, 5G n5, 5G n7, 5G n8, 5G n12, 5G n20, 5G n25, 5G n28, 5G n40, 5G n41, 5G n66, 5G n71, 5G n77, 5G n79, LTE B34, 5G n38, WCDMA B1, WCDMA B19, WCDMA B9
Max Transfer Rate
2.44 Gbps
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Expansion / Connectivity
Interfaces
1 x 2.5G/10 Gigabit Ethernet - RJ-45
Console: 1 x RJ-45
AUX: 1 x RJ-45
Expansion Slots
2 (total) / 2 (free) x Micro-SIM
Aerial
Aerial
External detachable
Power
Power Consumption Operational
21 Watt
Miscellaneous
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
10 - 85% (non-condensing)
