General
Device Type
Switch - 48 ports - L3 - Managed - stackable
Enclosure Type
Rack-mountable 1U
Ports
48 x 10/100/1000 + 4 x 10 Gigabit SFP+
Performance
Throughput: up to 190.5 Mpps
Routing/switching capacity: 256 Gbps
Capacity
Simultaneous VLANs: 4094
IPv4 routing table entries: 32768
IPv6 routing table entries: 16384
Routing Protocol
RIP-1, RIP-2, IGMPv2, IGMP, PIM-SM, IGMPv3, MSDP, MLD
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP, SSH-2, CLI, SCP
Authentication Method
Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2), HWTACACS
Features
Flow control, DHCP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, WRR queuing, IPv6 support, sFlow, STP support, RSTP support, VRRP support, MSTP support, PAgP support, ACL support, QoS, CAR, DHCP server, DLDP support, ECMP, STP Root Guard, IPv4 support, LLDP support, Smart Link Pass-Through, dynamic ARP protection, DHCP protection, port isolation, non blocking ports, SP, GARP, IRF technology, OpenFlow support, IP source guard
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3az
Expansion / Connectivity
Interfaces
48 x 1000Base-T RJ-45
4 x 10Gbit LAN SFP+
1 x serial (console)
1 x USB 2.0
1 x management (LAN) RJ-45
Expansion Slots
1 (total) / 1 (free) x Expansion Slot
Installed Modules Qty (Max)
1 (installed) / 1 (max)
Power
Power Device
Internal power supply (not installed)
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 120/230 V (50/60 Hz)
Miscellaneous
Compliant Standards
VCCI, EN 61000-3-2, AS/NZS 60950-1, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, GB 4943, ANSI C63.4-2009, EN 60825-2, EN 61000-3-3:2008, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-11:2004, EN 300 386 V1.6.1, VCCI V-3/2013.04 Class A, CISPR 24:2010, EN 55022:2010 Class A, FCC CFR47 Part 15 A, EN 61000-4.4:2012, CAN/CSA-C22.2 No. 60950-1
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - replacement - lifetime - response time: next business day
Technical support - phone consulting - 3 years
Environmental Parameters
Min Operating Temperature
-5 °C
Max Operating Temperature
45 °C
Humidity Range Operating
10 - 90% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 95% (non-condensing)
