General
Device Type
Radio access point
Networking
Connectivity Technology
Wireless, wired
Line Coding Format
64 QAM, 256 QAM, BPSK, QPSK, 1024 QAM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax
Frequency Band
2.4 GHz, 5 GHz
Performance
Maximum throughput (2.4 GHz): 574 Mbps
Maximum throughput (5 GHz): 1201 Mbps
Capacity
Maximum number of configured SSIDs: 16
Wireless clients per Wi-Fi radio: up to 512
Features
Surge protection, Mesh networking, Wireless Intrusion Detection System (WIDS), reset button, Wireless Intrusion Prevention System (WIPS), Dynamic Frequency Selection (DFS), 2x2 MU-MIMO technology, spectrum analyser, Packet Sniffer Mode, security slot (Kensington security lock compatible), Bluetooth (BLE) clients support, Target Wait Time (TWT), dedicated 3rd scanning radio, Wi-Fi 6 technology, BSS Coloring
Encryption Algorithm
TLS, PEAP, TTLS, WPA, WPA2, WEP, WPA3
Authentication Method
Radio Service Set ID (SSID), MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST, EAP-SIM, EAP-AKA, EAP-GTC
Compliant Standards
IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.3at, IEEE 802.11j, IEEE 802.3az, IEEE 802.11ac, IEEE 802.11r, IEEE 802.11v, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Aerial
Expansion / Connectivity
Interfaces
2 x 1000Base-T (PoE) - RJ-45
1 x management (RS-232) - RJ-45
1 x USB 2.0 - Type A
Miscellaneous
Included Accessories
Wall mounting kit, ceiling mounting kit, T-Rail mounting kit
Power
Power Over Ethernet (PoE) Supported
PoE
Power Consumption Operational
17 Watt
Dimensions & Weight (Shipping)
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
5 - 90% (non-condensing)
