General
Device Type
Switch - 24 ports - L2+ - Managed - stackable
Enclosure Type
Front to back airflow rack-mountable 1U
Ports
24 x SFP + 2 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ + 2 x 10 Gigabit SFP+
Performance
Switching capacity: 128 Gbps ¦ Forwarding performance: 95.2 Mpps ¦ Stacking bandwidth: 40 Gbps
Capacity
MAC addresses: up to 16000 ¦ Virtual interfaces (VLANs): 4094 ¦ IPv4 routes: up to 2000 ¦ IPv6 routes: up to 1000
MAC Address Table Size
16K entries
Routing Protocol
IGMPv2, IGMPv3, ECMP, policy-based routing (PBR), VRRPv3
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI
Encryption Algorithm
DES, Triple DES, RSA, MD5, SHA-1, TLS 1.0, SSL 3.0, SSL 2.0, PEAP, TTLS
Authentication Method
Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP)
Features
Flow control, BOOTP support, ARP support, VLAN support, IGMP snooping, Syslog support, traffic shaping, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, MAC address filtering, IPv6 support, firmware upgradable, Weighted Random Early Detection (WRED), sFlow, Rapid Spanning Tree Protocol (RSTP) support, VLAN Stacking, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Network Admissions Control (NAC), Jumbo Frames support, Dynamic ARP Inspection (DAI), Per-VLAN Spanning Tree Plus (PVST+), Equal-Cost Multipath (ECMP), STP Root Guard, LACP support, LLDP support, SNMP trap, DNS relay, Energy Efficient Ethernet, Dynamic VLAN Support (GVRP), loop prevention, enviromental monitoring, Ingress Layer 2 MAC Access Control Lists (ACLs), tagged VLAN, 4MB packet buffer
Compliant Standards
IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX
Built-in Devices
Led panel
Status Indicators
Fail, status
Expansion / Connectivity
Interfaces
24 x 1000Base-X SFP ¦ 1 x console RJ-45 management ¦ 2 x SFP+ ¦ 2 x network stack device SFP+ ¦ 1 x USB Type A
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Miscellaneous
Compliant Standards
FCC Class A certified, UL, TUV, cUL, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1, EN 60950-1, EN 60825-1, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A
Software / System Requirements
OS Required
AlliedWare Plus
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
5 - 90% (non-condensing)
Min Storage Temperature
-25 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 95% (non-condensing)
