General
Device Type
Radio access point
Built-in Devices
Light sensor, power sensor
Localisation
Rest of World
Networking
Connectivity Technology
Wireless
Line Coding Format
256 QAM, 1024 QAM
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6)
Frequency Band
2.4 GHz (1 band) / 5 GHz (2 bands)
Features
Direct Sequence Spread Spectrum (DSSS), packet aggregation A-MPDU, packet aggregation A-MSDU, Tri-Band, Orthogonal Frequency Division Multiplexing (OFDM), 2x2:2 MU-MIMO technology, 4x4:4 MU-MIMO technology, Bluetooth (BLE) clients support
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.15.4, IEEE 802.11ac Wave 2, IEEE 802.11ax
Aerial
Directivity
Omni-directional
Internet of Things (IoT)
Communications Technology
Bluetooth Low Energy (LE), Zigbee
Expansion / Connectivity
Interfaces
1 x 1/2.5GBase-T (PoE+) - RJ-45
1 x 1000Base-T - RJ-45
Miscellaneous
Included Accessories
Mounting kit
Compliant Standards
IEC 60601-1-2, ICES-003 Class B, IEC 60950-1, EN 60950-1, AS/NZS 4268, EN 60601-1-2, IP67, EN 50581:2012, EN 62479:2010, RoHS 2011/65/EU, EN 50385, EN 61000-3-3:2013, EN 62311:2008, EN 61000-3-2:2014, FCC CFR47 Part 15 B Class B, RSS-247, EN 55024:2010+A1:2015, EN 55011:2009+A1:2010, CISPR 32, FCC Subpart C 15.247, FCC Subpart E 15.407, EN 60601-1-2:2015, EN 300 328 V2.1.1, EN 55032:2015 Class B, EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1, EN 301 489-3 V2.1.1, EN 300 440 V2.1.1, IEC 62368, EN 62368, AN/NZS 60950.1, EN 301 893 V2.1.1, Intertek
Power
Power Over Ethernet (PoE) Supported
PoE+
Power Consumption Operational
15.23 Watt
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
60 °C
Humidity Range Operating
0 - 95% (non-condensing)
