General
Device Type
Network adapter
Interface (Bus) Type
PCI Express Half Mini Card
Networking
Connectivity Technology
Wireless
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0, IEEE 802.11ac
Data Transfer Rate
867 Mbps
Frequency Band
2.4 GHz, 5 GHz
Features
WMM support, WPS, WiDi, Intel Smart Connect Technology
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.3ac, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, Bluetooth 2.1, Bluetooth 3.0, Bluetooth 4.0, IEEE 802.11w
Miscellaneous
Encryption Algorithm
LEAP, 128-bit WEP, 64-bit WEP, TLS, PEAP, TTLS, TKIP, WPA, WPA2
Compliant Standards
UL, cUL, CB, IEC 60950-1, FIPS
Software / System Requirements
OS Required
Linux, Microsoft Windows 7, Windows 8
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
80 °C
Humidity Range Operating
50 - 90% (non-condensing)
